HCG-1000 Pro Primary Current Injection Test System (1000A)
This powerful test system is designed for primary injection testing of protective relay equipment and circuit breakers. It is also used to test the turns ratio of current transformers and for other applications that require high variable currents.
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product Overview
Specifications
| Output capacity | Max 5000VA |
| Output current | 0-1000A：1000A, 60s；900A, 90s；500A, 30min；≤300A, 24h |
| Primary current range | 0-1100A |
| Secondary current range | 0-6A |
| Secondary load test range | 1A: 0-10Ω @ 5A: 0～2Ω |
| Accuracy | Primary current: ±(0.005+0.2A) |
| Secondary current: ±(0.005+3dig) | |
| Voltage: ±(0.005+5dig) | |
| Turns ratio: ±(0.005+3dig) | |
| Storage and print | Built-in printer and storage |
| Current output cable | 70mm², 5m (Length can be customized upon request) |
| Input power | 200~240VAC, 50/60 Hz |
| Environmental conditions | Operating temperature: -10℃~50℃ |
| Humidity: ≤90% | |
| Net size | 530×290×480mm |
| Net weight | 38kg (without measuring cables) |
Features
Applications
1.Primary current injection testing and breaker testing
2.Testing current transformers
3.Testing integrity of ground grids and safety-ground devices
4.Heat runs
